Learn to make digital images and architectural drawings. Using industry software, lectures information, case studies, and tutorials, you will create digital collages, diagrams and drawings to represent an idea.

Prerequisite: ARH 170

Software: Rhino, Photoshop, Illustrator

Course Learning Outcomes



  • Translate 3D digital models into legible and accurate 2D architectural drawings
  • Draft orthographic architectural drawings using accurate drawing conventions
  • Create coherent visual presentations using an efficient workflow of multiple software programs
  • Explore ideas using Rhino digital modeling
  • Distill and edit building information to produce cogent and clear analytical diagrams
  • Articulate the differences between, and benefits of, parallel and perspective projections
  • Combine digital and analog drawing methods
